Description

The Leader In Suspension Technology For Turf

Featuring next-generation suspension technology – ForeFront™ Suspension, a 2-belt iCD™ cutting system, heavy-duty dual commercial Hydro-Gear® ZT-5400 drive system, and travel speeds up to 12 mph. Plus, select models feature EFI-ETC technology for fuel savings, easy starting, and smooth, consistent productivity.

Features
ForeFront™ Suspension System
Ride-On Mower Warranties
Vanguard BIG BLOCK™ Engine: The EFI-ETC engine with Oil Guard delivers a 500 hour oil change interval and 40 hp*, giving you added cutting performance to excel in thick, dense, and wet conditions. (select models)
Drive System: Dual, commercial Hydro-Gear® ZT-5400 Powertrain® transaxles with 9″ cooling fans
Premium High-Back Suspension Seat: Mow in superior comfort with arm rests, multi-position head rest, adjustable lumbar and seat recline
Hercules™ II Cast-Iron: Hercules™ II Cast-Iron; 10″ dia. cast-iron with industrial double row angular contact ball bearing with 1 3/16″ dia. shaft. Contact ball bearings with 1 3/16″ dia. shaft.
Vanguard Electronic Throttle Control: This new technology allows the engine to harness all the power that is generated for more consistent blade tip speed. (select models)
Specifications
Model Number: 5902067
Engine Brand: Vanguard™ BIG BLOCK™
Engine Power Rating *: 36
Displacement (cc): 993
PTO: Electric
Cylinders: 2
Fuel Type: Gasoline
Fuel Tank Capacity (gal): 11
Hour Meter/Instrumentation: Dual-function hour meter, fuel level gauge in each tank
Cutting Width (in): 60
Cutting Height (in): 1.5 – 5
Spindles: iCD™ Cutting System, 2-Belt
Suspension: ForeFront™ Suspension System
Transmission: Dual commercial Hydro-Gear® ZT-5400 Powertrain® transaxles with 9″ cooling fans
Deck Construction: iCD™ Cutting System, 2-Belt
Drive Axles (in): 1.375
Caster Tires (in): 13 x 6.5-6
Drive Tires (in): 26 x 12-12
Ground Speed-Fwd (mph): 0-12
Ground Speed-Rev (mph): 0-5
Overall Length (in): 84.5
Overall Width (in) Deflector Down/Deflector Up: 74/65
Dry Weight (lbs): 1496
Seat Package: Premium high-back suspension seat with adjustable arm rests, multi-position head rest, adjustable lumbar and back recline
Certified Roll-over Protection System: 158° foldable
Controls / Safety Group: Seat activated engine kill, clutch safety switch, neutral and parking brake safety circuit, adjustable twin steering controls
Parking Brake / Safety Circuit: Hand operated internal transaxle brake
Warranty (Engine) †: 3-Year limited manufacturer’s warranty
Warranty (Balance of Machine) †: 4-Year limited warranty (48 months) or 500 hours, whichever occurs first. Unlimited hours during the first 2 years (24 months). Coil-over-shocks and all suspension related components are covered for 5 years (60 months) unlimited hours. Belts, tires, brake pads, battery, blades: 90 days.
Starter: Electric
Engine Configuration: Vanguard™
